Electric Outboard Motor Epropulsion Spirit 1.0 Evo Tiller 3HP 1kW
Spirit 1.0 Evo is the first-ever electric outboard that features hydrogeneration. ePropulsion pioneers in the innovation of electric outboard motors and we dedicate ourselves to sustainable sailing.
The hydrogeneration data is based on real tests with the anti-ventilation plate installed.
|Spirit 1.0 Evo||Spirit 1.0 Evo Remote|
|Power||1 kW (3HP equivalent)||1 kW (3HP equivalent)|
|Standard Battery||Spirit Battery Plus, 1276 Wh li-ion polymer||Spirit Battery Plus, 1276 Wh li-ion polymer|
|Input Voltage||39V – 60V||39V – 60V|
|Motor Weight*||11.3 kg / 24.9 lbs||10.6 kg / 23.4 lbs|
|Battery Weight||8.7 kg / 19.2 lbs||8.7 kg / 19.2 lbs|
|Standard Charging||8.5 Hrs||8.5 Hrs|
|Fast Charging||3.5 Hrs||3.5 Hrs|
|External Battery||Yes, and E-Series Battery recommended||Yes, and E-Series Battery recommended|
|Propeller||11″ × 5.8″ 2-blade composite propeller||11″ × 5.8″ 2-blade composite propeller|
|Trim / Tilt Angle||0°, 7°, 14°, 21° / 85°||0°, 7°, 14°, 21° / 85°|
|Shaft Length||Short, Long||Short, Long|
|Control||Evo Tiller||Evo Top Mount Control / Evo Side Mount Control / Evo Dual Remote Control|
|Motor||Brushless DC motor||Brushless DC motor|
*The weight is measured with the short shaft version.
|Power (W)||Speed (mph / kph)||Runtime (hh:mm)||Range (mile / km)|
|35||2.2 / 3.5||36:25||80 / 129|
|65||2.7 / 4.3||19:35||53 / 85.3|
|125||3.5 / 5.6||10:00||35 / 56|
|250||4.4 / 7.1||5:00||22 / 35.5|
|500||5.3 / 8.5||2:30||13.3 / 21.3|
|750||5.7 / 9.2||1:40||9.5 / 15.3|
|1000||6.2 / 10||1:15||7.8 / 12.5|
At the core of Spirit 1.0 Evo electric outboard motor, it’s a 1kW BLDC motor, equivalent to 3HP.
*The performance data is based on a 12-foot aluminum boat with one person and one Spirit battery Plus in calm lake water. The actual speed, range and running time may vary because of different boats, load, weather, etc.
The integrated rechargeable battery is lightweight, only 19 lbs or 8.7 kg, and robust for tough conditions.
Never worry the battery drops into the water.
High energy density in a compact size to build large battery capacity.
180W Solar Charging
Dual power ports allow solar charging when discharging.
Extend the runtime to an entire day by replacing the integrated Spirit battery.
What’s in the Box
Yes, Spirit 1.0(R) Evo will switch off after 30 mins without operation.
Store the battery in the dry environment and keep the battery charge level at 60% around, and charge the battery every 3 months.
Yes, it is designed for extensive use in the saltwater. We choose high-quality aluminum alloy as the base material, and apply anodizing coating and powder coating on top of it.
